Jim Burnell's CCD Images - NGC2174 Clicking on an image will display a high-resolution view.



Object: NGC2174	Emission Nebula	Const.: Orion
Camera: QSI532	Scope: Vixen R200SS	Mount: Losmandy Titan
Filter(s): L:R:G:B	Exposure: 10x8m:4x8m:4x8m:4x8m	Paracorr
NGC2174 in Orion. This image is a color composite composed of a stack of 10 eight-minute exposures taken through an IR-block filter, (shown in the image below), used as the luminance channel, and stacks of 4 eight-minute exposures taken through red, green and blue filters for the colors. The image was acquired using a QSI532 CCD camera mounted on a Vixen R200SS, a 200mm f/8 Newtonian reflector equipped with a Tele Vue Paracorr. The exposures were calibrated, defect-corrected and stacked using AIP4WIN V2. This image has been resampled down from its original size of 2184x1472.



Object: NGC2174	Emission Nebula	Const.: Orion
Camera: QSI532	Scope: Vixen R200SS	Mount: Losmandy Titan
Filter(s): IR-block	Exposure: 10x8m	Paracorr
NGC2174 in Orion. This image is a stack of 10 eight-minute exposures taken through an IR-block filter. The image was acquired using a QSI532 CCD camera mounted on a Vixen R200SS, a 200mm f/8 Newtonian reflector equipped with a Tele Vue Paracorr. The exposures were calibrated, defect-corrected and stacked using AIP4WIN V2. This image has been resampled down from its original size of 2184x1472.
